Novopress ACO203XL 15-35mm Press Tool


Geberit

Novopress ACO203XL 15-35mm Press Tool


This kit comprises of a Novopress cordless ACO203XL press tool complete with 15-35mm jaws suitable for Geberit Mapress, Pegler Yorkshire Xpress, Sanha and M Press Fittings. The pressing tool ACO203XL sets new standards in the area of compatible pressings. Versatile applicable – 12 –108 mm for metal applications resp. 14 –110 mm for plastic applications. In comparison to its predecessor its handling is easier due to considerable savings in weight – only 3.9 kg. It is possible to use all authorised compatible jaws in the market with this tool. The XL-pressing tool of the new generation 203 makes faster pressings possible and achieves 40 % more pressing cycles per battery charge* due to its higher efficiency. Thanks to the new, implemented wireless technology device-related data can be requested via the NovoCheck app. Enquire about this product
£2,500.00

Plus VAT

Quantity

999 in stock

This kit comprises of a Novopress cordless ACO203XL press tool complete with 15-35mm jaws suitable for Geberit Mapress, Pegler Yorkshire Xpress, Sanha and M Press Fittings. The pressing tool ACO203XL sets new standards in the area of compatible pressings. Versatile applicable – 12 –108 mm for metal applications resp. 14 –110 mm for plastic applications. In comparison to its predecessor its handling is easier due to considerable savings in weight – only 3.9 kg. It is possible to use all authorised compatible jaws in the market with this tool. The XL-pressing tool of the new generation 203 makes faster pressings possible and achieves 40 % more pressing cycles per battery charge* due to its higher efficiency. Thanks to the new, implemented wireless technology device-related data can be requested via the NovoCheck app. Enquire about this product

Additional Information

Features:

  • Suitable for Geberit Mapress, Pegler Yorkshire Xpress, Sanha and M Press Fittings
  • Lighter and handier*
  • 12-108 mm with only one pressing tool (all materials)
  • 40 % more pressings per battery charge*
  • Rotatable head
  • Back stroke limitation – fast pressing with compatible jaws by an adaptable piston stroke
  • Less need for maintenance due to new motor technology
  • Thanks to the new, implemented wireless technology on ACO203, device-related data can be requested via the NovoCheck app.
  • Specification:

ACO203XL

Dimension Metal: up to 108 mm
Piston force: 32 kN
Piston stroke: 80 mm (optionally 40 mm)
Weight: 4.6 kg (inkl. Akku)
Length: 487 mm
Width: 79 mm
Height: 116 mm
Power consumption: 450 W
Battery:18 V Li-Ion 3,0 Ah
Battery capacity: up to 180 Press cycles
Charging time: approx. 60 min



Sales Offer

1 x ACO203XL Tool
2 x 3.0 Ah batteries
1 x 240v Charger
1 set of 15, 18, 22, 28, 35mm M profile jaws
Carry case

The ACO203XL tool is capable of pressing metal pipe upto 108mm. Please see our other sales offers for adapters and collars suitable for larger pipe diameters.

,

Downloads

Novopress ACO203XL press tool Instruction Manual
